Display: external PC and displayed by the upper computer software.
Operation Method: controlled by the upper computer software.
Threshold Contrast: it should be able to differentiate all four holes with diameters of 1.0mm, 1.5mm, 2.0mm and 2.5mm.
lmage Uniformity: no greater than 2%
Effective Scan lmage Area: 0#:22*35mm,1#:23*39mm, 2#: 30*40mm, 3#: 26*53mm
Adapter Input: 100 V-240 V~,50/60Hz,1.5A max.,
Main unit input: 15V DC,4.8A
Maximum Input Power: 145 VA
Working Environment: temperature:10℃~40℃; relative humidity:<80%; atmosphericpressure: 70 kPa~106 kPa
Storage and Transport Environment: -20℃~55 ℃; relative humidity: <93%; atmosphericpressure: 70 kPa~106 kPa
Dimension:305 mm x220 mmx180 mm
Net Weight: 6 kg
Gross Weight: 7 kg
